Advanced Schematic Features: For working on complex circuits, DipTrace includes multi-sheet and multi-level hierarchical capture tools.

It also allows the designer to create single / multi part components through templates by defining dimensions, electrical and visual pin factors, initiating a SPICE model and combining the pattern with a 3D model. With tools like BSDL import, pin naming and management, part handling becomes much easier.

Component Editor: DipTrace offers an intuitive component editing workspace.The ERC allows customization and the option to create constraints for additional modules, detecting unconnected pins, short circuits, single pin nets, and more. DRC with constraint manager: The new DipTrace platform has a better than ever design rule checker, which also supports electrical rules.In this section, we have given the details of the key features available in DipTrace.
